海奇芯片在多媒体SOC 领域拥有深厚的技术积累和市场理解，产品已广泛应用于消费电子、车载终端、商用显示以及投影等跨屏协同场景。在“算、显”分离领域是少数既掌握核心芯片设计研发技术又掌握智能设备互联软件协议的公司，在IC 和应用系统设计方面拥有自己的特色。
海奇产品由多个系列组成：
A系列产品主要应用于多屏互联、算显分离领域，该系列产品线也广泛应用于家庭多媒体播放器、卡拉OK 等产品；
B系列产品主要应用于带屏类商用显示产品，包含便携式播放器、车载多媒体中控、电子贺卡、数码相框、广告机、电子水牌、HMI 人机交互等多个领域；
C 系列可应用于对屏幕分辨率要求较高的商显市场，可支持4K 级解码和显示；
D 系列产品支持HDMI 输入并可驱动RGB/LVDS/MIPI 等主流屏幕接口，可用于投影仪、3D打印、商用电视、专用显示器等市场；
E 系列是海奇独有的多显接口类产品，可在支持HDMI 高清接口输入输出的同时，支持主流屏幕输出接口，典型应用包含卡拉OK 点唱机、会议设备等。
A系列产品
| Part No. | A111 | A210C/A211C | A3000 | A3100 | A3200 | A3300（A300) | A5000 | A5100 | A5200 |
| CPU | 800MHz | 800MHz | 1.0GHz | 1.0GHz | 1.0GHz | 1.0GHz | 1.2GHz | 1.2GHz | 1.2GHz |
| DRAM | 64MB SIP | ext. max. 256MB @800Mbps | 128MB SiP@1600Mbps | ext. max. 256MB @1333Mbps | ext. max. 256MB @1333Mbps | ext. max. 256MB @1333Mbps | 128MB SiP@1600Mbps | ext. max. 256MB @1333Mbps | ext. max. 256MB @1333Mbps |
| Flash | SPI Flash | SPI Flash | SPI Flash | SPI Flash | SPI / NAND | SPI Flash | SPI / NAND | SPI Flash | SPI / NAND |
| Video Decoder | Multi-format @FHD 60FPS | Multi-format @FHD 60FPS | Multi-format @FHD 60FPS | Multi-format @FHD 60FPS | Multi-format @FHD 60FPS | H.264@4K 30FPS | H.264@4K 30FPS | H.264@4K 30FPS | |
| Display | HDMI V1.4+VGA | HDMI V1.4 | HDMI_TX/VGA/CVBS | HDMI_TX VGA | HDMI_TX/VGA | HDMI_TX VGA | HDMI_TX/VGA/CVBS | HDMI_TX VGA | HDMI_TX/VGA |
| Video Input | N/A | CCIR601/656 | N/A | N/A | HDMI V1.4 | HDMI1.4 /CVBS | HDMI1.4 /CVBS | N/A | HDMI V1.4 |
| Audio | I2S in+out/SPDIF out | I2S in+out/SPDIF out | I2S in+I2S out/2ch PCM out/SPDIF out | I2S in+I2S out/2ch PCM out/SPDIF out | I2S in+I2S out/2ch PCM out/SPDIF out | I2S in+I2S out/2ch PCM out/SPDIF out | I2S in+I2S out/2ch PCM out/SPDIF out | I2S in+I2S out/2ch PCM out/SPDIF out | I2S in+I2S out/2ch PCM out/SPDIF out |
| USB | USB2.0 | USB2.0 | USB2.0x2 | USB2.0x2 | USB2.0x2 | USB2.0x2 | USB2.0x2 | USB2.0x2 | USB2.0x2 |
| HOST/Slavex2 | HOST/Slavex2 | ||||||||
| SDIO | SDIO2.0 | SDIO2.0 | SDIO3.0/eMMC4.4 | SDIO3.0 | SDIO3.0/eMMC4.4 | N/A | SDIO3.0/ EMMC4.4(4line) | SDIO3.0 | SDIO3.0/eMMC4.4 |
| 1data~4Data | 1data~5Data | ||||||||
| I2C/UART | 2xI2C+2xUart, IRRX | 2xI2C+3xUart, IRRX | 2xI2C+2xUart, IRRX | 3xI2C+2xUart,IRRX | 3xI2C+2xUart,IRRX， SAR ADCx2 | 3xI2C+2xUart,IRRX | Support 6xPWM 2xI2C+2xUart, IRRX | 3xI2C+2xUart,IRRX | 3xI2C+2xUart,IRRX， SAR ADCx2 |
| ,4xTPADC, 1xSARADC | |||||||||
| Ethernet | N/A | N/A | Support USB to Ethernet | RMII | RMII | N/A | RMII | RMII | RMII |
| Wi-Fi | A110 Support | A210C Support | Support | Support | Support | Support | Support | Support | Support |
| SW System | RTOS | RTOS | RTOS | Linux/RTOS | Linux/RTOS | Linux/RTOS | RTOS | Linux/RTOS | Linux/RTOS |
| Package | QFN68 | ELQFP128 | QFN68 | eLQFP128 | ELQFP176 | eLQFP128 | eLQFP128/QFN128 | eLQFP128 | ELQFP176 |
B、C系列产品
| Part No. | B100 | B200 | B3100 | B3200 | C3000 | C3100 | C3200 | C5000 | C5200 |
| CPU | 800MHz | 800MHz | 1.0GHz | 1.0GHz | 1.0GHz | 1.0GHz | 1.0GHz | 1.2GHz | 1.2GHz |
| DRAM | 64MB SIP | ext. max. 256MB @800MHz | max.256MB ext. | max.256MB ext. | 128MB SiP@1600Mbps | max.256MB ext. | max.256MB ext. | 128MB SiP@1600Mbps | max.256MB ext. |
| 1333Mbps | 1333Mbps | 1333Mbps | 1333Mbps | 1333Mbps | |||||
| Flash | SPI Flash | SPI Flash | SPI Flash | SPI / NAND | SPI / NAND | SPI Flash | SPI Flash | SPI / NAND | SPI Flash |
| Video Decoder | Multi-format @FHD 60fps | Multi-format @FHD 60FPS | Multi-format @FHD 60FPS | Multi-format @FHD 60FPS | Multi-format @FHD 60FPS | Multi-format @FHD 60FPS | H.264@4K 30FPS | H.264@4K 30FPS | |
| Display | RGB888+CVBS | RGB888 | RGB565/LVDS/CVBS | RGB888/LVDS/CVBS | RGB565/MIPI/LVDS/CVBS | MIPI/CVBS | RGB888/MIPI/LVDS | RGB565/MIPI/LVDS/CVBS | RGB888/MIPI/LVDS |
| Video Input | CCIR601/656 | CVBS | N/A | CCIR601/CCIR656/ CVBS | CVBS | CCIR601/CCIR656/ CVBS | CCIR601/CCIR656/ CVBS | CCIR601/CCIR656/ CVBS | |
| Audio | I2S in+I2S out/2ch PCM out/SPDIF out | I2S in+I2S out/2ch PCM out/SPDIF out | I2S in+I2S out/2ch PCM | I2S in+I2S out | I2S in+I2S out | I2S in+I2S out | I2S in+I2S out | I2S in+I2S out | I2S in+I2S out |
| out/SPDIF out | |||||||||
| USB | USB2.0x2 | USB2.0x2 | USB2.0x2 | USB2.0 Host+USB2.0 | USB2.0 Host+USB2.0 | USB2.0 Host+USB2.0 | USB2.0 Host+USB2.0 | USB2.0 Host+USB2.0 | |
| Host/Slave | Host/Slave | Host/Slave | Host/Slave | Host/Slave | |||||
| SDIO | SDIO2.0 | SDIO2.0 | SDIO3.0/ EMMC4.4(4line) | SDIO3.0/eMMC4.4 | SDIO3.0/ EMMC4.4(4line) | SDIO3.0/ EMMC4.4(4line) | SDIO3.0/eMMC4.4 | SDIO3.0/ EMMC4.4(4line) | SDIO3.0/eMMC4.4 |
| 1data~4Data | 1data~4Data | ||||||||
| I2C/UART | Support 2xI2C+2xUart,support IR receiver | 3xUART,4xTPADC, | 2xI2C+3xUart,T,4xTPADC, | Support 6xPWM， 3xUART,4xTPADC, | Support 6xPWM， 3xUART,4xTPADC, | Support 6xPWM， 3xUART,4xTPADC, | Support 6xPWM， 3xUART,4xTPADC, | Support 6xPWM， 3xUART,4xTPADC, | |
| 1xSARADC，IRRX | 1xSARADC | 1xSARADC,IRRX | 2xSARADC IRRX | 2xSARADC IRRX | 1xSARADC,IRRX | 2xSARADC IRRX | |||
| Ethernet | N/A | N/A | N/A | RMII | RMII | N/A | RMII | RMII | RMII |
| Wi-Fi | Support | B200/B200C | Support | Support | Support | Support | Support | Support | Support |
| Support | |||||||||
| SW System | RTOS | RTOS | RTOS/Linux | RTOS/Linux | RTOS/Linux | RTOS/Linux | RTOS/Linux | RTOS/Linux | |
| Package | QFN88 | ELQFP128 | eLQFP128 | QFP176 | eLQFP128 | eLQFP128 | eLQFP176 | eLQFP128 | eLQFP176 |
D、E系列产品
| Part No. | D3000 | D3100 | D3101 | D3200 | D5000 | D5200 | E100 | E3000 | E3100 |
| CPU | 1.0GHz | 1.0GHz | 1.0GHz | 1.0GHz | 1.0GHz | 1.2GHz | 800MHz | 1.2GHz | 1.2GHz |
| DRAM | 128MB SiP@1600Mbps | max.256MB ext. | max.256MB ext. | max.256MB ext. | 128MB SiP@1600Mbps | max.256MB ext. | 64MB SiP@1066Mbps | 128MB SIP@1600Mbps | max.256MB ext. |
| 1333Mbps | 1333Mbps | 1333Mbps | 1333Mbps | 1333Mbps | |||||
| Flash | SPI Flash | SPI Flash | SPI Flash | SPI Flash | SPI Flash | SPI Flash | SPI Flash | SPI Flash | SPI / NAND |
| Video Decoder | Multi-format @FHD 60FPS | Multi-format @FHD 60FPS | Multi-format @FHD 60FPS | Multi-format @FHD 60FPS | H.264@4K 30FPS | H.264@4K 30FPS | Multi-format @FHD 60FPS | H.264@4K 30FPS | H.264@4K 30FPS |
| Display | RGB888/MIPI/LVDS/CV BS | RGB565/LVDS | RGB565/LVDS | RGB888/MIPI/LVDS/CV BS | RGB888/MIPI/LVDS/CV BS | RGB888/MIPI/LVDS/CV BS | RGB888/HDMI | HDMI1.4/RGB/MIPI/LV DS | HDMI1.4/RGB888/LVDS |
| /MIPI/VGA | |||||||||
| Video Input | HDMI1.4 /CVBS | HDMI1.4 /CVBS | HDMI1.4 /CVBS | HDMI1.4 /CVBS | HDMI1.4 /CVBS | HDMI1.4 /CVBS | N/A | DVP/CSI2.0/HDMI1.4 | |
| /CVBS | |||||||||
| Audio | I2S in+I2S out | I2S in+I2S out | I2S in+I2S out | I2S in+I2S out | I2S in+I2S out | I2S in+I2S out | I2S in+out/SPDIF out | I2S in+I2S out/SPDIF out | I2S/4DMIC in &I2S 7.1 |
| out | |||||||||
| USB | USB2.0 Host+USB2.0 | USB2.0 Host+USB2.0 | USB2.0 Host+USB2.0 | USB2.0 Host+USB2.0 | USB2.0 Host+USB2.0 | USB2.0 Host+USB2.0 | USB2.0 HOST/Slavex2 | USB2.0x2 | USB2.0x2 |
| Host/Slave | Host/Slave | Host/Slave | Host/Slave | Host/Slave | Host/Slave | ||||
| SDIO | SDIO3.0/ EMMC4.4(4line) | SDIO3.0/ EMMC4.4(4line) | SDIO3.0/ EMMC4.4(4line) | SDIO3.0/ EMMC4.4(4line) | SDIO3.0/ EMMC4.4(4line) | SDIO3.0/ EMMC4.4(4line) | SDIO2.0 | SDIO3.0/eMMC4.4 | SDIO3.0/eMMC4.4 |
| I2C/UART | Support 6xPWM， 3xUART,4xTPADC, | Support 6xPWM， 2xUART 1xSARADC | Support 6xPWM， 2xUART 1xSARADC | Support 6xPWM， 3xUART, 1xSARADC | Support 6xPWM， 3xUART,4xTPADC, | Support 6xPWM， 3xUART, 1xSARADC | Support 2xI2C+2xUart,support | Support 6xPWM， 3xUART, 2xSARADC | Support 6xPWM， 3xUART,4xTPADC, |
| 1xSARADC,IRRX | IRRX | IRRX | IRRX | 1xSARADC,IRRX | IRRX | IR receiver | IRRX | 2xSARADC | |
| Ethernet | RMII | N/A | N/A | RMII | RMII | RMII | N/A | N/A | 100/1000M RMII |
| Wi-Fi | Support | Support | Support | Support | Support | Support | Suppport | Support | Support |
| SW | RTOS/Linux | RTOS/Linux | RTOS/Linux | RTOS/Linux | RTOS/Linux | RTOS/Linux | ROTS | RTOS/Linux | RTOS/Linux |
| System | |||||||||
| Package | eLQFP128/QFN124 | eLQFP128 | eLQFP128 | eLQFP176 | eLQFP128 | eLQFP176 | QFN124 | eLQFP128 | QFP216 |
珠海海奇半导体产品典型应用
